产品用途：产品用于河海各种船舶及海上石油平台等水上建筑一般控制装置用。 Scope of applications：The product uses in river sea each kind of ships and the marine petroleum platform and so on the aquatic building general control device uses |
执行标准：IEC60092-376或GB9332-88
Standards implemented：IEC60092-376 or GB9332-88
型号规格、燃烧特性及额定电压
Models specifications、Combustion and Rated voltage
|
型号Models |
燃烧特性 Combustion |
芯数 Core number |
标称截面(mm2) Nominal sectional area |
额定电压(KV) Rated Voltage |
温度 Temp.℃ |
| CKEF(HV)、CKEF(HV)80、CKEF(HV)90 CKEF(HV)82、CKEF(HV)92 |
DA SA NA |
2-37 |
0.75-1 |
0.25 |
E：85 J：85 V：70 |
| CKVV、CKVV80、CKVV90、CKVV82、CKVV92 | |||||
| CKJV、CKJV80、CKJV90、CKJV82、CKJV92、CKJP82、 CKJVP、CKJVP80、CKJVP90、CKJVP82、CKJVP92 | |||||
| CKEPJ、CKEPJ80、CKEPJ90、CKEPJ85、CKEPJ95、CKEPF CKEPF80、CKEPF90、CKEPF86、CKEPF96、CKJPF CKJPF80(90)、CKJPF86(96)、CKJP86、CKJPFP、CKJPFP80(90) CKJPFP86(96)、CKJ85、CKJ86、CKJPJ、CKJPJ80(90) CKJPJ85(95)、CKJP85、CKJPJP、CKJPJP80(90)、CKJPJP85(95) |
SC NSC |
0.5-2.5 |
85 |
产品名称及代号 Product descriptions and Codes
|
代号 Codes |
定义 Definition |
代号 Codes |
定义 Definition |
|
D |
单根燃烧 Combustion for single cable |
A |
有烟有酸有毒 have smoke acidity and toxicity |
|
S |
成束燃烧 Combustion for bunched cable |
B |
低烟低酸低毒 low smokelow aciditylow toxicity |
|
N |
耐火(单根燃烧) Fire-proof(Combustion for single cable) |
C |
无卤低烟低毒 Halogen freelow smokelow toxicity |
|
代号 Codes |
绝缘 Insulation |
代号 Codes |
内套 Inner- sheath |
代号 Codes |
铠装 Armoring |
代号 Codes |
外套 Outer sheath |
代号 Codes |
特 征 Chara-cteristic |
|
E |
乙丙橡胶绝缘 EP-rubber insulated |
F |
氯丁橡 胶护套 Chlorosul- conation sheath |
8 |
镀锡铜 丝编织 Tinned Cu wire woven |
0 |
无外 护套 NO- Outer sheath |
P |
线芯屏蔽 Line core screen |
|
J |
交联聚乙烯绝缘 XLPE Insulation |
H |
氯磺化聚 乙烯护套 Chlorosul- fonated polyethylene sheath |
9 |
镀锌钢 丝编织 Galva- nizes Steel wire woven |
2 |
聚氯乙 烯护套 Polyvinyl chloride sheath |
R |
软Soft |
|
V |
聚氯乙烯绝缘 PVC Insulation |
V |
聚氯乙 烯护套 Polyvinyl -chloride sheath |
- |
- |
5 |
交联聚 烯烃护套 Cross -linked polyolefin sheath |
- |
- |
|
X |
天然丁苯绝缘 NR/SBR insulated |
PF |
热塑性聚 烯烃护套 Thermosp- lasticity polyolefin sheath |
- |
- |
6 |
热塑性聚 烯烃护套 Thermos-plasticity polyolefin sheath |
- |
- |
|
- |
- |
PJ |
交联聚 烯烃护套 Cross- linked polyolefin sheath |
- |
- |
- |
- |
- |
- |
